2024-2026 Tesla Cybertruck 20-Inch Wheel: Specs, Curb Rash, and Replacement Guide
A complete reference for the factory 20x9" wheels on all Cybertruck models, covering technical specifications, common damage, and how to inspect a used wheel before you buy.
- The Cybertruck wheel has a unique 6x139.7 bolt pattern, +58.5mm offset, and 84mm center bore; these specs are critical for fitment.
- When buying used, prioritize inspecting for cracks and bends over cosmetic curb rash, as these can compromise safety.
- The lug nuts require a high torque of 151 lb-ft, which must be applied with a torque wrench.
- The distinctive aero covers are separate parts and are not typically included with a replacement wheel.
Technical Specifications
Verifying the exact specifications of your Cybertruck's wheels is critical before purchasing a replacement. These wheels are unique to the Cybertruck and not interchangeable with other vehicles. All trim levels, including All-Wheel Drive (AWD) and the Cyberbeast, use the same wheel specifications.
| Specification | Value |
|---|---|
| Size | 20x9" |
| Bolt Pattern | 6x139.7 mm (also known as 6x5.5") |
| Offset | +58.5 mm |
| Center Bore | 84 mm |
| Lug Nut Size / Thread | 21 mm / 14x1.50 |
| Lug Nut Torque | 151 lb-ft (205 Nm) |
| Wheel-Only Weight | 35.2 lbs (15.97 kg) |
| Weight with Aero Cover | 39.6 lbs (17.96 kg) |
| OEM Part Numbers | 1050222-00-C, 12502200C, 1250222, 1250221-00-D |
| Factory Tire Size | 285/65R20 |
| Factory Tire Options | Goodyear Wrangler Territory RT or Pirelli Scorpion ATR |
Warning: The wheel's offset is crucial. An incorrect offset can cause the tire to rub against the suspension or fender, and it can place improper stress on the wheel bearings, leading to premature failure. Always confirm the +58.5mm offset for OEM replacements.
Symptoms of a Damaged Wheel
Wheel damage can range from cosmetic to critical. It's important to diagnose the issue correctly to ensure safety.
- Vibration or Shaking: A bent wheel will often cause a noticeable vibration in the steering wheel or through the seat, especially at highway speeds (50-70 mph). This indicates the wheel is out of round and can no longer be properly balanced.
- Visible Damage: Obvious cracks, deep gouges, or bends in the wheel lip are clear signs of failure. Cracks often form near the lug nuts or on the spokes after a severe impact.
- Difficulty Balancing: If a tire shop cannot balance the wheel and tire assembly, it's a strong indication the wheel itself is bent.
- Air Loss: A crack in the wheel or a bend in the bead seat (where the tire seals against the wheel) can cause a slow, persistent air leak that is not related to a tire puncture.
Known Issues, Recalls, and TSBs
As of early 2026, there are no specific NHTSA recalls for the structural integrity of the Tesla Cybertruck's wheels themselves. However, there are related issues and recalls for the vehicle that buyers should be aware of.
- Aero Cover Issues: Early in the Cybertruck's release, there were reports of the aerodynamic wheel covers detaching from the vehicle or, in some cases, causing unusual wear on the tire's sidewall. Tesla was reportedly investigating the issue, and owners of used wheels should inspect the included aero covers for signs of damage or warping.
- Tire Pressure Monitoring System (TPMS) Recall: A recall was issued for a software issue where the TPMS warning light might not stay illuminated, failing to warn the driver of low tire pressure. This is resolved with an over-the-air software update and is not a fault of the wheel itself.
- No Widespread Structural Failures: While isolated incidents of wheel damage from extreme off-roading or impacts have been shared online, there is no evidence of a widespread manufacturing defect causing the wheels to fail under normal driving conditions.
Buying a Used 2024-2026 Cybertruck Wheel
Purchasing a used OEM wheel is a great way to save money, but a thorough inspection is essential to ensure you're getting a safe, usable part. The Cybertruck's weight and power put significant stress on the wheels, so a hidden flaw can be dangerous.
Step 1: Verify Compatibility
Confirm the part number (e.g., 1050222-00-C) and all key specifications: 20x9" size, 6x139.7 bolt pattern, and +58.5mm offset. While all Cybertrucks currently use this wheel, it's a good habit to verify.
Step 2: Physical Inspection Checklist
Never buy a used wheel sight-unseen. If buying online, demand high-resolution photos of every angle.
- Check for Cracks: This is the most critical check. Inspect the front and back of the wheel, paying close attention to the base of each spoke and the area around the lug nut holes. Use a flashlight to look for hairline fractures.
- Look for Bends: Lay the wheel on a flat surface. Place a straight edge across the front and back lip of the wheel. Rotate the wheel and check for any gaps between the straight edge and the wheel lip. Even a small bend can cause vibrations that are impossible to balance out.
- Inspect for Curb Rash: Scrapes and scuffs on the outer lip are common. Minor cosmetic rash is acceptable and can often be repaired. However, deep gouges that have removed significant material can weaken the wheel structure and should be avoided.
- Signs of Previous Repair: Look for evidence of welding (uneven beads of metal, discoloration), grinding marks, or body filler. A poorly repaired wheel is a major safety hazard. The finish should be uniform; patches of mismatched paint or clear coat suggest a spot repair.
- Check the Lug Nut Seats: The tapered surfaces where the lug nuts make contact should be clean and free of damage or elongation. Damaged seats can prevent the wheel from being torqued correctly.
Pro Tip: If possible, take the used wheel to a tire shop before purchasing. They can put it on a balancing machine, which will immediately reveal any significant bends that are hard to see with the naked eye.
OEM vs. Aftermarket
For a vehicle as new and heavy as the Cybertruck, a used OEM wheel is often a better choice than a new, cheap aftermarket one.
- Guaranteed Fitment: An OEM wheel is guaranteed to have the correct offset, center bore, and load rating for the Cybertruck.
- Proven Durability: The factory wheel has been tested by Tesla to withstand the vehicle's specific weight and torque. Aftermarket wheels, especially from lesser-known brands, may not be rated for the Cybertruck's demands.
- Material Quality: OEM wheels are typically made from high-quality cast aluminum. Forged aftermarket wheels are stronger and lighter but are significantly more expensive. 🎬 Watch: See how OEM wheels compare to aftermarket options for range. Cheaper cast aftermarket wheels may not have the same strength as the factory part.
Cost Comparison
Prices can vary based on condition and availability. The Cybertruck is a new vehicle, so the market for used parts is still developing.
| Part or Service | Estimated Cost | Notes |
|---|---|---|
| New OEM Wheel (from Tesla) | $400 - $600 | Price for a single wheel, without tire, TPMS, or aero cover. |
| New Aftermarket Wheel | $350 - $1,200+ | Varies widely by brand and construction (cast vs. forged). |
| Used OEM Wheel | $250 - $500 | Dependent on condition. A wheel with heavy curb rash will be cheaper than a pristine one. |
| Curb Rash Repair (Professional) | $100 - $250 per wheel | Cost depends on the severity of the damage and the wheel finish. |
| Shop Labor (Mount & Balance) | $25 - $50 per wheel | Cost to mount a tire onto the wheel and balance the assembly. |
Frequently Asked Questions (FAQ)
Do I need to replace the wheel for minor curb rash?
No, minor cosmetic curb rash does not typically require a full wheel replacement. It can be professionally repaired for a fraction of the cost of a new wheel. However, if the rash is very deep or has caused a crack or bend, the wheel should be replaced for safety.
What is the lug nut torque spec for the Cybertruck?
The correct lug nut torque specification is 151 lb-ft (or 205 Nm). It is critical to use a torque wrench to tighten the lug nuts to this exact specification to ensure the wheel is properly secured.
Are the aero covers included with a replacement wheel?
Generally, no. The aero covers are considered a separate part from the wheel itself. When buying a new or used wheel, confirm whether the cover is included. A new cover from Tesla costs around $75.
Can I use aftermarket wheels on my Cybertruck?
Yes, but you must be extremely careful. The aftermarket wheel must have the correct 6x139.7 bolt pattern, a center bore of 84mm or larger (with hub-centric rings if needed), and an offset close to the factory +58.5mm. Most importantly, it must have a load rating sufficient for the Cybertruck's high curb weight.
Helpful Videos
Cost Comparison
Technical Specifications
OEM Part Numbers: 1050222-00-C 12502200C 1250221-00-D 1250221D 1250222
Size: 20x9", Bolt Pattern: 6x139.7mm, Offset: +58.5mm, Center Bore: 84mm, Lug Nut Torque: 151 lb-ft
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
